HKD type ring chain electric hoist
HKD type ring chain electric hoist
HKD type ring chain electric hoist
HKD type ring chain electric hoist
HKD type ring chain electric hoist
HKD type ring chain electric hoist

HKD type ring chain electric hoist

Add Favorites Send Inquiry

Member Details

BEIJING GOLDEN BERRY INTERNATIONAL TRADING CORPORATION,LTD

Baoding,Hebei,China

View More>
  • Product Details
  • Company Profile

1. High strength aluminum alloy body, beautiful appearance, compact, smart & light 2. Two gear transmission, high speed for helical gear drive, smooth transmission, low noise. 3. High intensity, main components are used high alloy steel material, and through the special heat treatment process. 4. High strength, good wear resistance, up and down hooks use high strength alloy steel production, the heat treatment succeed to high toughness, Avoid brittle fracture of the plastic hook when overloading. HKD ring chain electric hoist features: Shell: aluminum alloy shell, solid and light, with special heat sink, heat fast, can be used continuously, the efficiency of up to 40%, the overall sealing structure, can be used in chemical plants, electroplating factories and other places. Pounds of magnetic brake: the recent design of the magnetic generator, which is special for the production of magnetic. Can be cut off at the same time the brake, to ensure that the brake is absolutely safe when the crane. Limit switch: lift on lift off has a limit switch device, automatic stop, prevent the chain beyond, to ensure the safety of. Chain: imported FEC80 super heating treatment of alloy steel chain. Safe use of water, sea water, chemicals, and other adverse conditions. Hook: after hot forging, great strength. Not easy to break. Under the hook can rotate 360. With a safe tongue, to ensure safe operation. Support frame: the lifting support frame is composed of two pieces of steel plate, which is very strong. Transformer: 24V/36V transformer. Operation in case of leakage, can prevent accidents, when it rains, and even to ensure safe use. Electromagnetic contactor: high efficiency electromagnetic contact, can be used at high frequency, no problem. Mechanical brake: double brake system is safe and reliable. Reverse protection device: special wire device, when the power line is wrong, the control circuit can not move. Button switch: the use of waterproof button switch, li

Technical parameter：
Model Up weight Lifting height Lifting speed Lifting motor Execute motor Beam orbit
power speed Phase Voltage frequency power speed running speed Phase number Voltage frequency
HKDL0501 0.5 3/9 6.8 0.75 1440 3 380 50 0.4 1440 11/21 3 380 50 58-153
HKDL102 1 3/9 3.4 0.75 1440 3 380 50 0.4 1440 11/21 3 380 50 58-153
HKDL101 1 3/9 6.6 1.5 1440 3 380 50 0.4 1440 11/21 3 380 50 58-153
HKDL1501 1.5 3/9 8.8 3.0 1440 3 380 50 0.4 1440 11/21 3 380 50 82-178
HKDL201 2 3/9 6.6 3.0 1440 3 380 50 0.4 1440 11/21 3 380 50 82-178
HKDL202 2 3/9 3.3 1.5 1440 3 380 50 0.4 1440 11/21 3 380 50 82-178
HKDL2501 2.5 3/9 5.4 3.0 1440 3 380 50 0.75 1440 11/21 3 380 50 100-178
HKDL301 3 3/9 5.4 3.0 1440 3 380 50 0.75 1440 11 3 380 50 100-178
HKDL302 3 3/9 4.4 3.0 1440 3 380 50 0.75 1440 11 3 380 50 100-178
HKDL303 3 3/9 2.2 1.5 1440 3 380 50 0.75 1440 11 3 380 50 100-178
HKDL502 5 3/9 2.7 3.0 1440 3 380 50 0.75 1440 11 3 380 50 100-178



















Size specification sheet：

Model Up weight（kg） Company（mm） China
H A B E I K L N W U R T
HKDL00501 0.5 610 455 285 165 Φ31 Φ34 25 19 206 111 142 231 Φ6.3
HKDL0102 1 665 455 285 165 Φ31 Φ42 32 24 206 111 142 231 Φ6.3
HKDL0101 1 650 525 300 178 Φ31 Φ42 32 24 260 111 142 231 Φ7.1
HKDL01501 1.5 770 615 430 265 Φ38 Φ49 40 30 237 127 142 231 Φ10.0
HKDL0201 2 770 615 430 265 Φ38 Φ49 40 30 237 127 142 231 Φ10.0
HKDL0202 2 815 525 300 238 Φ38 Φ49 40 30 237 127 142 231 Φ7.1
HKDL02501 2.5 830 615 430 265 Φ43 Φ59 48 35 265 140 142 231 Φ11.2
HKDL0301 3 830 615 430 265 Φ43 Φ59 48 35 265 140 142 231 Φ11.2
HKDL0302 3 930 615 430 320 Φ43 Φ59 48 35 265 140 142 231 Φ10.0
HKDL0303 3 940 525 350 205 Φ43 Φ59 48 35 265 140 142 231 Φ7.1
HKDL0502 5 1015 615 430 325 Φ54 Φ60 48 43 296 156 142 231 Φ11.2
